6105E Utility Tractor
Make:
John Deere
Model:
6105E Utility Tractor
- Engine HP: 106 Max | 105 Rated
- John Deere FT4 PowerTech™ engine combines performance and fluid economy
- 12/12 or 24/12 hi-lo PowrReverser™ transmission
- Cab, open station, 2WD or MFWD
- 15 degrees of seat swivel with optional air-ride seat
Specifications | |
---|---|
Engine description | John Deere PowerTech™ PWL (B20 Diesel Compatible) |
Engine displacement | 4.5 L275 cu in. |
Rated engine power | 97/68EC: 77 kW105 engine hp |
Rated PTO power (hp SAE) | 66 kW89 PTO hp |
Transmission type | Standard: John Deere 12F/12R PowrReverser™ Transmission: 30 km/h19 mphOptional: John Deere 24F/12R PowrReverser Transmission: 40 km/h25 mph |
Hydraulic pump rated output | 36.5 cc pump: 75.7 L/min20 gpm |
Rear hitch category (SAE designation) | Category 2: 2500 kg (5500 lb) standard lift at 610 mm behind hitchpointOptional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610 mm behind hitchpoint |
Description | John Deere PowerTech™ PWL (B20 Diesel Compatible) |
Engine type | Diesel, in-line, 4-cylinders, wet-sleever cylinder lingers with 4 valves-in-head |
Engine family | HJDXL04.5315 |
Rated speed | 2200 rpm |
Aspiration | Turbocharged, wastegate turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation |
Emission level | Final Tier 4 |
After treatment type | DOC/DPF/SCR |
Displacement | 4.5 L275 cu in. |
Rated power | 97/68EC: 77 kW105 engine hp |
Rated PTO power (hp SAE) | 66 kW89 PTO hp |
Engine peak torque | At 1,600 rpm: 432 Nm318 lb-ft |
PTO torque rise | 30 percent |
Type | Standard: John Deere 12F/12R PowrReverser™ Transmission: 30 km/h19 mphOptional: John Deere 24F/12R PowrReverser Transmission: 40 km/h25 mph |
Type | Open-centerGear driven |
Pump rated output | 36.5 cc pump: 75.7 L/min20 gpm |
Available flow at a single rear SCV | 75.7 L/min20 gpm |
Number of rear selective control valves (SCVs) | Standard: ISO Couplers: 2Optional: ISO Couplers 3 |
SCV control | Mechanical |
Hitch category (SAE designation) | Category 2: 2500 kg (5500 lb) standard lift at 610 mm behind hitchpointOptional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610 mm behind hitchpoint |
Maximum lift capacity behind lift points | Standard: Category 2 with heavy duty lift: 3318 kg7300 lb |
Sensing type | Optional |
Drawbar category | Standard: Category 2Optional: Category 2 heavy duty |
Maximum vertical load | Standard: Category 2 1000-1250 kg2205-2756 lbOptional: Category 2 heavy duty: 1200-1900 kg2645-4189 lbMaximum vertical load dependent on drawbar position |
Type | IndependentStandard: 35 mm (1.375 in.) 540 rpm/1000 rpm reversible shaft |
Engine rpm (at rated PTO speeds) | 2085 engine rpm at 540 rpm PTO2067 engine rpm at 1000 rpm PTO |
Type | Flange |
Final drive type | Inboard Planetary |
Rear differential lock | Full-locking mechanical |
Type | Standard: MFWDOptional: 2WD |
Front axle differential lock | 2WD: NoneMFWD: limited slip |
Wheel tread range | 2WD: 1533-2043 mm60.4-80.4 in.MFWD: 1516-2016 mm59.7-79.4 in. |
Alternator size | 90 amp |
Battery options | 12 V |
Total cold cranking amps | 925 CCA |
Seat | Standard: Mechanical suspension cloth seatOptional: Air suspension |
Instructional seat | Optional |
Display | LCD instrument cluster |
Wheelbase | 2WD: 2456 mm96.7 in.MFWD: 2450 mm96.5 in. |
Approximate shipping weight, Open;Cab | 2WD: Open: 4064 kg8960 lbMFWD: Open: 4268 kg9410 lbCab: 4645 kg10,240 lb |
Maximum ballast level | 6464 kg14250 lb |
Crankcase oil volume | 15 L4 U.S. gal. |
Fuel tank | 168 L44.4 U.S. gal. |
Cooling system | Open station: 18.6 L4.7 U.S. gal.Cab: 19.1 L5 U.S. gal. |
Transmission-hydraulic system | 58 L15.3 U.S. gal. |
Interval for engine oil change | 500 hours |
Interval for hydraulic/transmission oil change | 1,000 hours |
Interval for engine coolant change | 5,000 hours |
Country of manufacture | Mexico |
