<ul>
<li>Hydrafloat™ allows the operator to match changing field conditions</li>
<li>Dual-knife drive system is timed</li>
<li>Cutterbar is closer to the ground</li>
<li>Conveniently store optional spare knives</li>
</ul>

740D Draper Platform

Agriculture

<ul>
<li>AutoConnect™ deck compatible for deck attach/detach in seconds</li>
<li>Cab or Open Station configuration available</li>
<li>PowrReverser™ or E-hydro transmission with Twin Touch™ pedals</li>
</ul>

3039R Compact Utility Tractor

Key Features
<ul>
<li>Engine Power: 125 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>

5125r-tractor

5125R Utility Tractor

Key Features
<ul>
<li>Engine Power: 115 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>

5115r-tractor

5115R Utility Tractor

Key Features
<ul>
<li>Engine Power: 100 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>

5100r-tractor

5100R Utility Tractor

Key Features
<ul>
<li>Engine Power: 90 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>

5090r-tractor

5090R Utility Tractor

Key Features
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>

5115m-powrquad-pluspowr8-utility-tractor

5115M Utility Tractor

<div class="key_features">Key Features
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>
</div>

5100m-powrquad-pluspowr8-utility-tractor

5100M Utility Tractor

<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>

5090m-powrquad-pluspowr8-utility-tractor

5090M Utility Tractor

<ul>
<li>2WD or MFWD</li>
<li>5-year Powertrain warranty*</li>
<li>Available in premium cab, standard cab or open operator station</li>
<li>No Regen required</li>
</ul>

5067E Utility Tractors

<div class="key_features">
<ul>
<li>67 engine hp</li>
<li>Best-in-class visibility</li>
<li>Thick comfortable seat</li>
<li>5-Year Powertrain Warranty</li>
</ul>
</div>
<a class="no_show_m btn btn-larger btn-primary btn-product btn-raq various" href="https://www.agprocompanies.com/new-equipment/agriculture/tractors/5-series-tractors/small-frame/5065e-utility-tractor/#inquire">REQUEST A QUOTE</a>

5065e-utility-tractor

5065E Utility Tractor

Draper Platforms

<ul>
<li>Hydrafloat™ allows the operator to match changing field conditions</li>
<li>Dual-knife drive system is timed</li>
<li>Cutterbar is closer to the ground</li>
</ul>

730D Draper Platform

<ul>
<li>Harvest crops as close as possible to the ground with the HydraFlex™ cutterbar</li>
<li>Minimize grain loss with a two-speed center feed section</li>
<li>Enable higher harvesting speed without sacrificing cut quality with a 4” double cut, dual drive, shaft driven cutterbar</li>
<li>Get more done by eliminating header calibrations</li>
</ul>

RD35F HydraFlex™ Draper

<ul>
<li>Capture more crop in rolling and uneven terrain with a wing range of over 30&#8243; </li>
<li>Achieve desired stubble height with Position Control Gauge Wheels</li>
<li>Reduce cutterbar loss with Grain Saver Draper Belts</li>
<li>Improve harvest logistics with a factory-installed Integrated Transport system</li>
</ul>

HD35R Hinged Frame, Rigid Cutterbar Draper

<ul>
<li>Hydrafloat™ allows the operator to match changing field conditions</li>
<li>Double-cut knife system produces a cleaner cut</li>
<li>Cutterbar is closer to the ground</li>
<li>Stainless-steel feed floor</li>
</ul>

735D Draper Platform

RD30F HydraFlex™ Draper

<ul>
<li>Hydrafloat™ allows the operator to match changing field conditions</li>
<li>Double-cut knife system produces a cleaner cut</li>
<li>Dual-knife drive system is timed</li>
<li>Cutterbar is closer to the ground</li>
</ul>

725D Draper Platform

RD45F HydraFlex™ Draper

RD40F HydraFlex™ Draper

<ul>
<li>Capture more crop in rolling and uneven terrain with a wing range of over 45”</li>
<li>Easily cut all crops with a consistent reel-to-cutterbar distance and improved reel torque</li>
<li>Achieve desired stubble height with Position Control Gauge Wheels</li>
<li>Reduce cutterbar loss with Grain Saver Draper Belts</li>
</ul>

HD50R Hinged Frame, Rigid Cutterbar Draper

Harvesting Equipment

<ul>
<li>Minimize tire and track damage from stubble with Stalk Deflectors</li>
<li>Easily harvest down and leaning corn with Active End Fenders </li>
<li>Size residue less than 6 inches with RowMax™ Chopping Stalk Rolls</li>
</ul>

C6R Corn Head

<ul>
<li>HydraFlex™ float system improves operator control</li>
<li>Epicyclic knife drive increases drive capacity</li>
<li>600 Flex Header height sensors for rigid mode</li>
<li>Less reel, mounting, and drive parts</li>
</ul>

635F HydraFlex™ Cutting Platform

<ul>
<li>Epicyclic knife drive to increase drive capacity</li>
<li>Safe and damage-free storage</li>
<li>Raised-height skid shoe</li>
<li>Perma-Glide™ floating divider points</li>
</ul>

622F HydraFlex™ Cutting Platform

<ul>
<li>Combine Advisor™ package helps to set, optimize and automate combine functions when conditions change</li>
<li>Spacious and comfortable cab with everything you need to easily control your harvest right at your fingertips</li>
<li>Continued quality manufacturing of S-Series combines maximizes uptime and productivity</li>
</ul>

S790 Combine

<ul>
<li>Easily transport between fields with improved visibility</li>
<li>Get done faster with industry leading fold and unfold times</li>
<li>Ready to harvest corn heads with factory installed Stalk Deflectors and Active End Fenders</li>
<li>Size residue less than 6 inches with RowMax™ Chopping Stalk Rolls</li>
</ul>

C12F Folding Corn Head

John Deere

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat with arm rests</li>
<li>LED lights, floor mat, front bumper, rear hitch, covered storage come standard</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>

Z330R ZTrak™ Mower with 48-in. Deck

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat and standard rear hitch</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>

Z330M ZTrak™ Mower with 48-in. Deck

<ul>
<li>48-inch (122-cm) floating mower deck</li>
<li>Powerful 19 hp (14.2 kW) V-twin engine</li>
<li>Self-propelled hydrostatic drive system</li>
<li>Easy-to-use controls for operator comfort and convenience</li>
</ul>

W48R Commercial Walk-Behind Mower

Rippers

Semi-Mounted Rotary Rakes

Horizontal Fold Disc Mowers

Front Mounted Disc Mowers

Professional-Duty Roadside Mowers

Vari-Manager Series

Vertical Fold Disc Mowers

Landscape and Estate Shredders

Trailed Round Bale Wrappers

Trailed Square Bale Wrappers

Harvesting equipment, cutters, shredders, hay &amp; forage equipment, planting &amp; seeding equipment, sprayers and tillage equipment

BALR: Farm Equipment

<div>

 The center feed drum is designed for efficient and consistent feeding of the crop into the combine feeder house. Beginning with model year 2020 700D Draper Platforms, customers will have the ability to choose between a 356-mm (14-in.) or 406-mm (16-in.) center feed drum to be factory installed. Feature benefit:
 <ul>
 <li>356-mm (14-in.) or 406-mm (16-in.) diameter factory-installed feed drum significantly improves feeding of the crop</li>
 <li>Strategic location improves crop handling and capacity, increasing productivity in high-volume crops such as irrigated wheat, barley, or canola</li>
 <li>Combine performance is improved due to retractable fingers that enable smoother feeding</li>
 <li>Capacity increase in tough conditions by 20 percent due to an upgraded center feed section slip clutch</li>
 </ul>

 Functionality:

 The feed drum protrudes forward from the draper back sheets, improving the crop handoff from the draper side belts. An increase in slip clutch torque of the center feed drum from 1200 Nm to 1650 Nm allows for increased capacity in tough crop conditions

 In some crop conditions, crop can hesitate at the corners of the feed drum but the retractable drum fingers keep the crop moving into the combine.
 </div>

Two available sizes for a 700D factory-installed center feed drum improves feeding of crop into the combine feeder house

<div>

 The 730D, 735D, and 740D Draper models can be equipped with an integrated, slow-speed transport system.

 John Deere value:
 <ul>
 <li>Need for a header trailer is eliminated due to dual-front dolly wheel tires with an extendable tongue and two-gauge wheel tires that can carry the complete weight of the draper when in transport</li>
 <li>Road transport is quicker and easier because one person can convert the draper from field to transport mode in a few minutes without the use of tools</li>
 </ul>
 <h5>Theory of operation</h5>

 In field mode, the dual wheels become the left- and right-hand gauge wheels. For transport, the left-hand dual-dolly wheels support one side of the draper frame and the right-hand dual wheels are repositioned to support the right-hand end of the frame.

 The transport package includes warning lights, which can be plugged into a seven-way power source for road transport with a 32.2-km/h (20-mph) speed limit for farm equipment transport.

 NOTE: The 730D, 735D, and 740D Drapers are equipped with two ST215/75R14 gauge wheel tires as base equipment and four ST215/75D14 gauge wheels with the low-speed transport option.
 </div>

Takes one person a few minutes to convert draper from field to transport without use of tools

<div>


 The unique dual-knife drive system is timed, creating the smoothest-possible reciprocating knife-drive system currently in the industry. The positive, reliable shaft-driven dual epicyclical in-line knife drives with built-in driveline protection, provide operators with the strongest knife-drive system.
 </div>

Dual-knife drive system is timed

<div>

 All John Deere 700D Drapers include a double-cut knife which features a hydraulic tilt that is controlled from inside the cab. All 10.6-m (35-ft) and 12.1-m (40-ft) draper cutterbars have knifeback reinforcement straps to strengthen the knifeback.

 Feature benefit:
 <ul>
 <li>Maximized productivity through longer stroke of knife section provides a faster, cleaner, and smoother cut, which allows operators to harvest at faster ground speeds</li>
 <li>Productivity is maximized in tough conditions through a reinforced knifeback that strengthens the cutterbar</li>
 <li>Reduced cost of operation and increased wear life with hardened sickle sections and unique boron treatment</li>
 <li>Hydraulic tilt optimizes the cutterbar angle for varying conditions, extending the harvest day and providing the lowest-possible cut height</li>
 </ul>

 <h5>Functionality</h5>

 The 100-mm (4-in.) cutting action produces a cleaner cut versus the tearing effect of shorter-stroke cutting systems. Knife hold-downs are easily adjusted to help maintain harvesting performance.

 The cutterbar hydraulic tilt adjusts a full 8 degrees while maintaining excellent visibility to the cutterbar throughout the tilt range. For improved ease of use, the hydro handle can be configured to control the platform tilt.
 </div>

Double-cut knife system produces a cleaner cut

<div>

 Reel resume and reverse are features on the 700D Drapers. The combine operator can store two different reel positions with one setting for normal conditions and another for down, tangled, short, or leaning crops.

 Feature benefit:
 <ul>
 <li>Added time savings and convenience with saved reel positions, lowering operator fatigue</li>
 <li>Increased harvest efficiency through a reel-reverse feature that reverses the reel in conjunction with the center feed drum and belt to back out plugs</li>
 </ul>

 </div>

Specifications
Cutterbar length	12.3 m40.5 ft
Knife drive	Base: dual knife
Knife speed	490 cycles/min
Pickup reel operating speeds	6-54 rpm
Draper belts speed control	Hydraulic from cab
Type	Straight-line knife drive system
Length	12.3 m40.5 ft
Knife drive	Base: dual knife
Knife speed	490 cycles/min
Cutterbar tilt	Base: hydraulic, maximum tilt 9 degree (angle)
Number of slats	Six bat poly base
Fingers	Nylon
Diameter	1.067 m3.5 ft
Height control	Hydraulic
Speed control	Hydraulic
Reel lift	Cylinder stroke: 330 mm13 in.Total range: 391.5 mm15.4 in.
Reel fore and aft	Cylinder stroke: 359 mm14.1 in.Total range: 620 mm24.4 in.
Reel resume	Base
Reel reverse	Base
Operating speeds	6-54 rpm
Width	Side belts: 1.02 m3.33 ftCenter belts: 1.4 m4.583 ftCenter belt not included with SPW configuration
Cleat height	Cleats: 25.4 mm1 in.
Operating speed	Side belts: variable up to 223 m/min735 fpmCenter belts: 212 m/min695 fpmCenter belt not included with SPW configuration
Speed control	Hydraulic from cab
Center belt reverse	Base: center belt not included with SPW configuration
Diameter	Two factory-installed options: 356 or 406 mm14 or 16 in.Feed drum not included with SPW configuration
Feed drum fingers	Heavy-duty and round with breakaway notch and retainerDiameter: 16 mm0.625 in.
Number of fingers	18
Auger finger platform	Dual chevron, retracting
Finger reach	152 mm6 in.
Drum/auger reverse	Base
Operating speed	196 rpm
Center cleanout door	Base
Type	Base: electrohydraulic
Header height sensing on the ground	Base
Header height sensing off the ground	Base
Type	Optional: hydraulic drive
Platform length	13.1 m42.9 ft
Overall operating depth	2.5 m8.2 ft
Transport width, field position	12.95 m42.5 ft
Transport width on wheel, less dividers	2.7 m8.9 ft
Transport length, hitch extended	15.4 m50.4 ft
