<ul>
<li>Rated Operating Capacity: 1407 kg (3,100 lb.)</li>
<li>Gross Horsepower: 68.0 kW (91.2 hp)</li>
<li>Net Horsepower: 66.0 kW (88.5 hp)</li>
<li>Operating Weight: 5403 kg (11,900 lb.)</li>
</ul>


331G Compact Track Loader

Agriculture

<ul>
<li>AutoConnect™ deck compatible for deck attach/detach in seconds</li>
<li>Cab or Open Station configuration available</li>
<li>PowrReverser™ or E-hydro transmission with Twin Touch™ pedals</li>
</ul>


3039R Compact Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 125 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5125r-tractor

5125R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 115 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5115r-tractor

5115R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 100 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5100r-tractor

5100R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 90 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5090r-tractor

5090R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>


5115m-powrquad-pluspowr8-utility-tractor

5115M Utility Tractor

<div class="key_features"><strong class="text_large">Key Features</strong></p>
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>
</div>


5100m-powrquad-pluspowr8-utility-tractor

5100M Utility Tractor

<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>


5090m-powrquad-pluspowr8-utility-tractor

5090M Utility Tractor

<ul>
<li>2WD or MFWD</li>
<li>5-year Powertrain warranty*</li>
<li>Available in premium cab, standard cab or open operator station</li>
<li>No Regen required</li>
</ul>


5067E Utility Tractors

<div class="key_features">
<ul>
<li>67 engine hp</li>
<li>Best-in-class visibility</li>
<li>Thick comfortable seat</li>
<li>5-Year Powertrain Warranty</li>
</ul>
</div>
<p><a class="no_show_m btn btn-larger btn-primary btn-product btn-raq various" href="https://www.agprocompanies.com/new-equipment/agriculture/tractors/5-series-tractors/small-frame/5065e-utility-tractor/#inquire">REQUEST A QUOTE</a></p>


5065e-utility-tractor

5065E Utility Tractor

Compact Track Loaders

<ul>
<li>Rated Operating Capacity: 1176 kg (2,590 lb.)</li>
<li>Gross Horsepower: 54.8 kW (74 hp)</li>
<li>Net Horsepower: 52.5 kW (70 net hp)</li>
<li>Operating Weight: 4313 kg (9,500 lb.)</li>
</ul>


325G Compact Track Loader

<ul>
<li>Rated Operating Capacity: 965 kg (2,125 lb.)</li>
<li>Gross Horsepower: 48.5 kW (65 hp)</li>
<li>Net Horsepower: 45.6 kW (61 hp)</li>
<li>Operating Weight: 3824 kg (8,423 lb.)</li>
</ul>


317G Compact Track Loader

<ul>
<li>Rated Operating Capacity: 1680 kg (3,700 lb.)</li>
<li>Gross Horsepower: 74.6 kW (100 hp)</li>
<li>Net Horsepower: 72.0 kW (96.6 hp)</li>
<li>Operating Weight: 5493 kg (12,100 lb.)</li>
</ul>


333G Compact Track Loader

Construction

<ul>
<li>Rated Operating Capacity: 1362 kg (3,000 lb.)</li>
<li>Gross Horsepower: 68.0 kW (91.2 hp)</li>
<li>Net Horsepower: 66 kW (88.5 hp)</li>
<li>Operating Weight: 4495 kg (9,900 lb.)</li>
</ul>


330G Skid Steer

<ul>
<li>Net Power: 17.4 kW (23.3 hp)</li>
<li>Max. Digging Depth: 3.06 m (10 ft. 0 in.)</li>
<li>Operating Weight: 3690 kg (8,135 lb.)</li>
</ul>


35G Compact Excavator

<ul>
<li>Net Power: 52 kW (71 hp)</li>
<li>Operating Weight: 6400 kg (14,110 lb.)</li>
<li>Bucket Capacity: 0.8–1.6 m<sup>3</sup> (1.0–2.1<br />
cu. yd.)</li>
</ul>


324L Compact Wheel Loader

<ul>
<li>Net Power: 26.8 kW (35.9 hp)</li>
<li>Max. Digging Depth: 3.53 m (11 ft. 7 in.)</li>
<li>Operating Weight: 4920 kg (10,847 lb.)</li>
</ul>


50G Compact Excavator

<ul>
<li>Compatible with 2032R and 2038R tractors</li>
<li>Quik-Park&trade; mounting system for easy on, easy off in minutes</li>
<li>Optional single-point hydraulic coupler connects hydraulics with pull of a lever</li>
<li>Quik-Change&trade; Bucket System for fast and easy attachment changeovers</li>
<li>Mechanical Self-Leveling (MSL) Loader option with 1,377 lb (626 kg) lift capacity</li>
</ul>


220R Loader

<ul>
<li>Net Power: 48 kW (65 hp) @ 2,400 rpm</li>
<li>Operating Weight: 5796 kg (12,778 lb.)</li>
<li>Bucket Capacity: 0.8–1.6 m³ (1.0–2.1 cu. yd.)</li>
</ul>


304L Compact Wheel Loader

<ul>
<li>Automatic Mast Latch for fast implement changeover</li>
<li>Repositioned leveling links for better visibility</li>
<li>Designed for maximum tractor maneuverability</li>
<li>Integrated stands for tool free attachment and removal</li>
</ul>


620R Loader

<ul>
<li>Compatible with 3025D, 3035D, 3043D, 3025E, 3032E, and 3038E</li>
<li>Curved boom design improves operator visibility to front implements</li>
<li>Larger knee plates for strength and durability without sacrificing compact stance</li>
<li>845 lbs (384 kg) of lift capacity</li>
<li>Mechanical Self-Leveling (MSL) Loader option with 1,283 lb (583 kg) lift capacity</li>
</ul>


300E Loader

John Deere

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat with arm rests</li>
<li>LED lights, floor mat, front bumper, rear hitch, covered storage come standard</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>


Z330R ZTrak™ Mower with 48-in. Deck

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat and standard rear hitch</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>


Z330M ZTrak™ Mower with 48-in. Deck

<ul>
<li>48-inch (122-cm) floating mower deck</li>
<li>Powerful 19 hp (14.2 kW) V-twin engine</li>
<li>Self-propelled hydrostatic drive system</li>
<li>Easy-to-use controls for operator comfort and convenience</li>
</ul>


W48R Commercial Walk-Behind Mower

Loaders

<ul>
<li>Net Power: 45 kW (61 hp) @ 2,200 rpm</li>
<li>Operating Weight: 5355 kg (11,806 lb.)</li>
<li>Bucket Capacity: 0.8-1.1 m³ (1.0-1.4 cu. yd.)</li>
</ul>


204L Compact Wheel Loader

<ul>
<li>Rated Operating Capacity: 1634 kg (3,600 lb.)</li>
<li>Gross Horsepower: 74.6 kW (100 hp)</li>
<li>Net Horsepower: 72 kW (96.6 hp)</li>
<li>Operating Weight: 4540 kg (10,000 lb.)</li>
</ul>


332G Skid Steer

Rippers

Semi-Mounted Rotary Rakes

Horizontal Fold Disc Mowers

Front Mounted Disc Mowers

Professional-Duty Roadside Mowers

Vari-Manager Series

Vertical Fold Disc Mowers

Landscape and Estate Shredders

Trailed Round Bale Wrappers

Trailed Square Bale Wrappers

Download Grade Management Brochure

<p>Models 317G, 325G, 331G, and 333G with operating capacities of 2,250 &#8211; 3,700 lbs</p>


CTLD: Compact Track Loaders

<div>

       <p>With over 100 attachments offered in the John Deere portfolio you can make the most out of your skid steer by equipping it with a number of popular attachments.</p>
       <ul>
        <li>Increased auxiliary hydraulic flows and power over previous models enable greater performance while running attachments and optional high-flow hydraulics lets operators better utilize attachments like snow blowers, rotary cutters, or brooms</li>
        <li>Internally mounted auxiliary couplers and sleeves mean that couplers and hoses are better protected from damage</li>
        <li>Optional electrically actuated Quik-Tatch<sup>TM </sup>enables some attachment connecting to take place within the cab reducing the need for exiting and re-entering the cab to manually connect attachments.</li>
        <li>Creep control (offered within the Joystick Performance Package) allows operators to perform precise tasks that require full hydraulic flow and power while running at lower travel speeds</li>
       </ul>
       <p>For additional information on attachments and compatibility, check out the <a href="https://www.deere.com/assets/pdfs/common/products/attachments/construction/John-Deere-Construction-Attachments-Full-DKAPROCCE.pdf">John Deere attachments guide.</a></p>
       <p> </p>
      </div>

Increase your machine’s versatility with John Deere’s wide array of attachment offerings

<div>

       <p>The spacious and pressurized cab means operators can stay fresh throughout the entire workday through designs that minimize noise levels and keep water and dust out. Switchable controls allow an operator to choose the pattern they prefer (ISO, H-pattern, foot controls, or ISO plus foot controls) meaning they can get to work quicker and easier.</p>
       <p> </p>
       <ul>
        <li>The ergonomic design includes a larger and continuous footwell to allow for extra room and repositioning of the operator’s feet to maximize comfort</li>
        <li>Controls are in operator-friendly locations that allow for repetitive movements to take place easier meaning that operators will not tire out as quick throughout the day</li>
        <li>Multiple slip-resistant steps and six handles mounted on the interior and exterior of the machine result in a safer and more natural way to get in and out of the cab</li>
        <li>Expertly designed HVAC system with vents spaced along the side, bottom, and rear of the cab allow for work to take place in any season and keeps the operator comfortable with strategically placed vents.</li>
       </ul>
       <p> </p>
      </div>

Enjoy all day comfort with the spacious and ergonomically friendly cab

<div>

       <p>A: EH Self-Level (up and down) <br>B: EH Self-Level (up only)<br>C: Return to Carry (RTC) <br>D: Return to Dig (RTD)<br>E: Boom Height Kickout (BHKO)</p>
       <p> </p>
       <p>The optional factory-installed EH boom performance package offers increased productivity through shorter cycle times for applications where repetitive boom functions are common by automating these functions and setting them to match operator preference from inside the cab.</p>
       <p> </p>
       <ul>
        <li>RTD allows the operator to automatically set the bucket or other attachment to their designated ready-to-work position RTC allows the operator to use the joystick detents to automatically reset the boom to a designated ready-to-carry position</li>
        <li>BHKO allows the operator to pre-select a specific boom height based on truck/hopper height and use joystick detents to automatically stop at a specific height</li>
        <li>Electronic Self-Level (ESL) allows the Self-Level to work during boom up and down, unlike the hydraulic Self-Level option that works only on boom up </li>
       </ul>
      </div>

Maximize productivity with the electro-hydraulic (EH) boom performance package

<div>

       <p>Skid steers and CTL’s have features that result in higher productivity in applications like V-pattern truck loading, bale handling, and grading when compared to the competition. </p>
       <p> </p>
       <ul>
        <li>Increased bucket breakout forces result in better handling of pallets of pavers or other heavy materials in addition to helping heap the bucket with larger loads.</li>
        <li>Anti-stall feature monitors engine load to quickly prevent the engine from stalling allowing the operator to use the maximum horsepower efficiently when pushing large amounts of material</li>
        <li>Differential steering allows the operator to maintain speed and traction when pushing through a turn</li>
        <li>Standard two-speed drivetrain delivers travel speeds up to 8mps for CTL’s that allow operators to get from one side of the job to the other much quicker</li>
       </ul>
      </div>

Productivity enhancements that can benefit you regardless of the machine’s application

<div>

       <p>Enhanced serviceability features and ease of access to daily and preventative maintenance points ensures that these tasks do not significantly cut into working hours</p>
       <p> </p>
       <ul>
        <li>The hood tilts up for ground level access to the dipstick, fuel and fluid filler necks, filters, and see-through reservoirs</li>
        <li>The cab can swing up and out of the way in less than five minutes for wide-open drivetrain access. A single person can safely and efficiently lift the boom and lock it out, exit the machine, raise the cab, and remove the footwell.</li>
        <li>Removable metal side panels on the left and rear are lightweight and perforated with handles at optimized lifting points.</li>
        <li>The removal of the footwell with just six total nuts and bolts allows for easy cleaning of dirt and debris that enters the cab.</li>
       </ul>
      </div>

Ease of serviceability allows you to spend more time completing the tasks at hand

<div>

       <p>Enhanced visibility features enable the operator to view the jobsite to be as precise and productive as possible while also increasing jobsite awareness.</p>
       <ul>
        <li>Optional deluxe LED lighting provides increased visibility early in the morning or at night over the standard halogen package.</li>
        <li>Clear sight from the seat under the boom arms to see the tires, even when the boom is down and great visibility to the cutting edges and Quik-Tatch™ lock and unlock indicators.</li>
        <li>Rear view camera, low-sloped hood and a high cross-tube on the upper-linkage result in unmatched rear visibility.</li>
       </ul>
      </div>

Specifications
Engine Manufacturer	Yanmar
Engine Model	4TNV94FHT
Emission Rating	EPA Tier 4 / EU Stage IV
Aspiration	Turbo. Intercooled
Displacement, ltr (Inches³)	3.1 (186.3)
Rated Speed, rpm	2500
Engine Output - Net, kW (hp)	66 (88.5)
Engine Output - Gross, kW (hp)	68 (91.2)
Torque, Nm (lbf / ft)	382 (281.8)
Track Shoe Width, mm (inches)	400 (15.8)
Length - No Bucket, mm (inches)	3100 (122)
Length - Foundry Bucket, mm (inches)	3710 (146)
Width - No Bucket, mm (inches)	2000 (78.9)
Height - Top Of Cab, mm (inches)	2200 (86.7)
Ground Clearance, mm (inches)	240 (9.4)
Rear Departure Angle, Degrees	31
Height to Hinge Pin, mm (inches)	3350 (132)
Dump Angle, Degrees	48
Dump Height - Maximum Foundry, mm (inches)	2690 (106.1)
Rollback - Ground Level, Degrees	35
Rated Operating Capacity - Foundry, kg (lbs)	1407 (3100)
Tipping Load - Foundry, kg (lbs)	4021 (8857)
Ground Bearing Pressure - Foundry, kPa (PSI)	38.1 (5.5)
Speed - Maximum, kph (mph)	12.6 (7.8)
Breakout - Lift Foundry, kN (lbf)	26.6 (6000)
Breakout - Bucket Foundry, kN (lbf)	45.9 (10325)
Hydraulic Power, kW (hp)	31.402 (42.1)
Hydraulic Power - Option, kW (hp)	54.168 (72.6)
Pump Flow, lt/min (gallons (US) / min)	80 (23.5)
Pump Flow - Option, lt/min (gallons (US) / min)	138 (36.5)
System Pressure, bar (PSI)	237.87 (3450)
