<ul>
<li>Net Power: 52 kW (71 hp)</li>
<li>Operating Weight: 6400 kg (14,110 lb.)</li>
<li>Bucket Capacity: 0.8–1.6 m<sup>3</sup> (1.0–2.1<br />
cu. yd.)</li>
</ul>


324L Compact Wheel Loader

Agriculture

<ul>
<li>AutoConnect™ deck compatible for deck attach/detach in seconds</li>
<li>Cab or Open Station configuration available</li>
<li>PowrReverser™ or E-hydro transmission with Twin Touch™ pedals</li>
</ul>


3039R Compact Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 125 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5125r-tractor

5125R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 115 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5115r-tractor

5115R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 100 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5100r-tractor

5100R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>Engine Power: 90 hp</li>
<li>Easy to use transmission</li>
<li>NEW integrated technologies (JDLink™, AutoTrac™)</li>
<li>NEW optional suspended front axle</li>
</ul>


5090r-tractor

5090R Utility Tractor

<p><strong class="text_large">Key Features</strong></p>
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>


5115m-powrquad-pluspowr8-utility-tractor

5115M Utility Tractor

<div class="key_features"><strong class="text_large">Key Features</strong></p>
<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>
</div>


5100m-powrquad-pluspowr8-utility-tractor

5100M Utility Tractor

<ul>
<li>PowrQuad PLUS 16F/16R or Powr8 32F/16R transmission options</li>
<li>Climate-controlled cab</li>
<li>Hitch lift capacity of 6,970 lbs. with an option of 7,860 lbs.</li>
<li>Integrated AutoTrac™ guidance</li>
</ul>


5090m-powrquad-pluspowr8-utility-tractor

5090M Utility Tractor

<ul>
<li>2WD or MFWD</li>
<li>5-year Powertrain warranty*</li>
<li>Available in premium cab, standard cab or open operator station</li>
<li>No Regen required</li>
</ul>


5067E Utility Tractors

<div class="key_features">
<ul>
<li>67 engine hp</li>
<li>Best-in-class visibility</li>
<li>Thick comfortable seat</li>
<li>5-Year Powertrain Warranty</li>
</ul>
</div>
<p><a class="no_show_m btn btn-larger btn-primary btn-product btn-raq various" href="https://www.agprocompanies.com/new-equipment/agriculture/tractors/5-series-tractors/small-frame/5065e-utility-tractor/#inquire">REQUEST A QUOTE</a></p>


5065e-utility-tractor

5065E Utility Tractor

Compact Wheel Loaders

<ul>
<li>Net Power: 48 kW (65 hp) @ 2,400 rpm</li>
<li>Operating Weight: 5796 kg (12,778 lb.)</li>
<li>Bucket Capacity: 0.8–1.6 m³ (1.0–2.1 cu. yd.)</li>
</ul>


304L Compact Wheel Loader

<ul>
<li>Net Power: 45 kW (61 hp) @ 2,200 rpm</li>
<li>Operating Weight: 5355 kg (11,806 lb.)</li>
<li>Bucket Capacity: 0.8-1.1 m³ (1.0-1.4 cu. yd.)</li>
</ul>


204L Compact Wheel Loader

<ul>
<li>Net Power: 76 kW (103 hp)</li>
<li>Operating Weight: 8860 kg (19,533 lb.)</li>
<li>Bucket Capacity: 1.5–2.0 m<sup>3</sup> (2.0–2.6<br />
cu. yd.)</li>
</ul>


344L Compact Wheel Loader

<ul>
<li>Net Power: 52 kW (71 hp)</li>
<li>Operating Weight: 5560 kg (12,258 lb.)</li>
<li>Bucket Capacity: 0.8–1.1 m<sup>3</sup> (1.0–1.4<br />
cu. yd.)</li>
</ul>


244L Compact Wheel Loader

Construction

<ul>
<li>Rated Operating Capacity: 1362 kg (3,000 lb.)</li>
<li>Gross Horsepower: 68.0 kW (91.2 hp)</li>
<li>Net Horsepower: 66 kW (88.5 hp)</li>
<li>Operating Weight: 4495 kg (9,900 lb.)</li>
</ul>


330G Skid Steer

<ul>
<li>Rated Operating Capacity: 1407 kg (3,100 lb.)</li>
<li>Gross Horsepower: 68.0 kW (91.2 hp)</li>
<li>Net Horsepower: 66.0 kW (88.5 hp)</li>
<li>Operating Weight: 5403 kg (11,900 lb.)</li>
</ul>


331G Compact Track Loader

<ul>
<li>Net Power: 17.4 kW (23.3 hp)</li>
<li>Max. Digging Depth: 3.06 m (10 ft. 0 in.)</li>
<li>Operating Weight: 3690 kg (8,135 lb.)</li>
</ul>


35G Compact Excavator

<ul>
<li>Net Power: 26.8 kW (35.9 hp)</li>
<li>Max. Digging Depth: 3.53 m (11 ft. 7 in.)</li>
<li>Operating Weight: 4920 kg (10,847 lb.)</li>
</ul>


50G Compact Excavator

<ul>
<li>Rated Operating Capacity: 1176 kg (2,590 lb.)</li>
<li>Gross Horsepower: 54.8 kW (74 hp)</li>
<li>Net Horsepower: 52.5 kW (70 net hp)</li>
<li>Operating Weight: 4313 kg (9,500 lb.)</li>
</ul>


325G Compact Track Loader

<ul>
<li>Compatible with 2032R and 2038R tractors</li>
<li>Quik-Park&trade; mounting system for easy on, easy off in minutes</li>
<li>Optional single-point hydraulic coupler connects hydraulics with pull of a lever</li>
<li>Quik-Change&trade; Bucket System for fast and easy attachment changeovers</li>
<li>Mechanical Self-Leveling (MSL) Loader option with 1,377 lb (626 kg) lift capacity</li>
</ul>


220R Loader

<ul>
<li>Automatic Mast Latch for fast implement changeover</li>
<li>Repositioned leveling links for better visibility</li>
<li>Designed for maximum tractor maneuverability</li>
<li>Integrated stands for tool free attachment and removal</li>
</ul>


620R Loader

<ul>
<li>Compatible with 3025D, 3035D, 3043D, 3025E, 3032E, and 3038E</li>
<li>Curved boom design improves operator visibility to front implements</li>
<li>Larger knee plates for strength and durability without sacrificing compact stance</li>
<li>845 lbs (384 kg) of lift capacity</li>
<li>Mechanical Self-Leveling (MSL) Loader option with 1,283 lb (583 kg) lift capacity</li>
</ul>


300E Loader

John Deere

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat with arm rests</li>
<li>LED lights, floor mat, front bumper, rear hitch, covered storage come standard</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>


Z330R ZTrak™ Mower with 48-in. Deck

<ul>
<li>Mow up to 2 acres</li>
<li>23 HP* (17 kW) V-Twin engine</li>
<li>48- and 54-in. (122- and 137 cm) forged Accel Deep™ Mower Decks available</li>
<li>20-inch (50.8 cm) high-back custom-tailored seat and standard rear hitch</li>
<li>3-year/200-hour bumper-to-bumper warranty**</li>
</ul>


Z330M ZTrak™ Mower with 48-in. Deck

<ul>
<li>48-inch (122-cm) floating mower deck</li>
<li>Powerful 19 hp (14.2 kW) V-twin engine</li>
<li>Self-propelled hydrostatic drive system</li>
<li>Easy-to-use controls for operator comfort and convenience</li>
</ul>


W48R Commercial Walk-Behind Mower

Loaders

<ul>
<li>Rated Operating Capacity: 1634 kg (3,600 lb.)</li>
<li>Gross Horsepower: 74.6 kW (100 hp)</li>
<li>Net Horsepower: 72 kW (96.6 hp)</li>
<li>Operating Weight: 4540 kg (10,000 lb.)</li>
</ul>


332G Skid Steer

Rippers

Semi-Mounted Rotary Rakes

Horizontal Fold Disc Mowers

Front Mounted Disc Mowers

Professional-Duty Roadside Mowers

Vari-Manager Series

Vertical Fold Disc Mowers

Landscape and Estate Shredders

Trailed Round Bale Wrappers

Trailed Square Bale Wrappers

Wheel Loaders

Download Product Brochure

<p>Models 204L, 244L, 304L, 324L, and 344L ranging 61 &#8211; 103 hp with 1 &#8211; 3 cubic yard bucket capacities</p>


WLDB: Compact Wheel Loader

<div>


       <p>L-series compact wheel loaders feature industry exclusive Articulation Plus™ that adds rear wheel steer to increase full turn tipping load and overall maneuverability</p>
       <ul>
        <li>This steering system combines 30 degrees of articulation with an additional 10degrees of rear-wheel steering.</li>
        <li>Articulation Plus enables a significantly higher full turn tipping load than machines without this feature because the machine does not need to articulate as much to turn as other loaders</li>
        <li>This feature results in a significantly tighter turning radius than comparatively sized loaders without Articulation Plus™</li>
       </ul>
      </div>

Tighter Turning Radius and Increased Stability with Articulation Plus™ Steering

<div>



       <p>With over 100 attachments offered in the John Deere attachment portfolio you can make the most out of your compact wheel loader by equipping it with many popular attachments.</p>
       <ul>
        <li>Skid Steer Quik-Tatch coupler and ISO Style Couplers allow increased optionality to utilize a range of attachments and the common interface means previous series attachments will be able to be used on these new series of machines as well.</li>
        <li>The Attachment Assist Package makes it easier for operators to get the most out of attachments by combining throttle lock and creep control to maintain full power at a set ground speed. </li>
        <li>Optional three function hydraulics includes joystick with integrated FNR switch and 3<sup>rd</sup> function mini-joystick control for ease of operation.</li>
        <li>Standard auxiliary hydraulics and optional High Flow hydraulics allows the use of attachments like snow blowers or augers.  By simply pressing a switch in the cab, operators can easily connect and disconnect attachments and enable them to have full function flow without having to manually press buttons throughout the day</li>
        <li>Optimized forks for compact wheel loaders offer improved visibility, increased capacity, and better durability.  Designed specifically for compact loaders, they enable operators to load the far side of a trailer with ease</li>
        <li>Optional 14 pin connector enables additional attachments to be compatible with the machines</li>
       </ul>
      </div>

Increase your machine’s versatility with John Deere’s wide array of attachment offerings

<div>



       <p>The operator focused designs found within John Deere Compact Wheel loaders ensure operators are comfortable and productive all day.</p>
       <ul>
        <li>L-series wheel loaders feature an overall larger cab that is both wider and longer compared to previous series</li>
        <li>To help keep operators more comfortable during a long shift, an improved air conditioning system with additional adjustable louvers has been included. The optimized duct work and additional operator louvers provide increased airflow and allow the operator to direct airflow where it is needed.</li>
        <li>Ergonomic, low effort controls all on the right side, allow operators to work comfortably and more efficient.</li>
        <li>Machine display is redesigned and mounted to the cab A-frame and is height adjustable</li>
        <li>Ample storage within the cab allows operators to keep personal items close and secure</li>
        <li>Adjustable steering column in enclosed cab units allows operators to easily move the steering wheel to a desired position to help increase productivity and allow easy ingress and egress.</li>
        <li>Optional premium high-back, air suspension heated seat provides top of the line comfort for operators in off road conditions and colder climates</li>
        <li>The left pedal acts as a brake and inching pedal.  If the operator pushes all the way down, the machine comes to a complete stop.  If the operator presses the pedal without going all the way down, the machine will proportionally move slower and continue at that speed</li>
       </ul>
      </div>

Enjoy all day comfort with the spacious and ergonomically friendly cab

<div>


       <p>Compact Wheel Loaders come with features that result in higher productivity in applications like V-pattern truck loading, bale handling, and landscaping </p>
       <ul>
        <li>The Yanmar 4TNV98CT Engine features a high pressure common rail fuel system and a turbocharger. Both machines meet Final Tier 4 emissions regulations through the use of cooled exhaust gas recirculation (EGR), a diesel oxidation catalyst (DOC), and a diesel particulate filter (DPF). Because the 244L and 324L are under 75 gross horse power, diesel exhaust fluid is not needed.</li>
        <li>Based off of customer and dealer feedback, the 244L and 324L have an increased maximum travel speed of 38 km/h (23 mph).</li>
        <li>Automatic shift logic has been internally developed specifically for this machine to allow the operator to focus on their work instead of shifting gears. This allows the machine to seamlessly transition from loading to transport. The system senses the machine speed and load and will adjust the hydrostatic pumps, motors, and gearbox automatically without operator input to best match the conditions.</li>
        <li>Manual low-speed 100-percent differential lock delivers the ground gripping tractive effort necessary to dive deep into the pile and help heap the bucket.</li>
        <li>Optional ride control reduces material spillage from the bucket when traveling over rough and uneven terrain by cushioning the boom. This will help in getting the material being moved to where it is intended to go, and will reduce site cleanup that may result from spilled material.</li>
        <li>High lift linkage option on the 324L adds additional height to hinge pin to increase things like dump height and reach</li>
        <li>The 244L and 324L include rim pull control that allows adjustment of tractive effort for better operation in loose underfoot conditions. It allows customers to adjust the machine to the operating conditions to help prevent the tires from spinning and therefore improve tire life and powertrain life.</li>
       </ul>
      </div>

Productivity enhancements that can benefit you regardless of the machine’s application

<div>


       <p>Enhanced serviceability features and ease of access to daily and preventative maintenance points ensures that these tasks do not significantly cut into working hours</p>
       <ul>
        <li>Ground level service simplifies daily maintenance, keeping machine in good working condition without cutting into working hours.  This also enables operators to change fluids quickly and cleanly to keep equipment running smoothly</li>
        <li>A redesigned cooling package optimizes efficiency and cleanout. The unique diagonal flow through design is efficient because it minimizes contamination from debris build up. This significantly reduces material buildup on the coolers. The coolers are also spaced to allow ease of access for cleanout from ground level.</li>
        <li>To maximize time spent on the job instead of in the shop, compact wheel loaders feature extended service intervals for engine oil and filter, final drive oil, and hydraulic oil.</li>
        <li>Customers and dealers will now have optionality to install JDLink on these machines allowing them a range of benefits such as location tracking, fuel usage, and machine alerts.</li>
        <li>Compact wheel loaders are supported by one of the largest dealer networks in the industry meaning more technicians in the shop and field and more parts on the shelf to keep machines up and running.</li>
        <li>The automatic spring-applied hydraulically released park brakes help maximize uptime and are a safer and more reliable feature than most competitor’s cable operated park brakes.</li>
       </ul>
      </div>

Ease of serviceability allows you to spend more time completing the tasks at hand

<div>



       <p>Compact Wheel Loaders are built with operator visibility in mind.  From the tapered boom to the rear sloping hood and everything in between, operators will have best in class visibility to all sides of the machine.</p>
       <ul>
        <li>Single boom and bucket cylinder in line with each other helps ensure the operator is able to efficiently change out between attachments</li>
        <li>Tapered boom design has been optimized for improved parallel lifting capabilities especially when forks are being used in applications like landscaping.  The design also provides excellent viewing of attachments and material.</li>
        <li>Sloped rear hood and rear-view mirrors allow superior views to the rear of the machine when backing up</li>
        <li>Compact wheel loaders offer great visibility for the operator by positioning them higher up in the cab compared with other compact construction equipment.</li>
        <li>Optional LED lighting package that offers two different styles of LED lights, results in increased productivity in low light conditions due to significantly better illumination of the machine surroundings.  It will also result in a more durable and reliable light source over time when compared to standard halogen bulbs.</li>
       </ul>
      </div>

Specifications
Engine Manufacturer	Yanmar
Engine Model	4TNV98CT
Emission Rating	EPA Tier 4
Displacement, ltr (Inches³)	3.3 (203)
Rated Speed, rpm	2400
Engine Output - Net, kW (hp)	52 (71)
Torque, Nm (lbf / ft)	280 (206)
Transmission Type	Hydrostatic
Front Differential Type	Locking
Rear Differential Type	Open
Tire size - Standard	405 / 70 R18
Service Brake - Type	Wet Disc & Drum
Service Brake - Actuation	Hydraulic
Parking Brake - Type	Wet Disc
Height - Over Cab, mm (ft/in)	2780 (9 ft 1 in)
Wheelbase, mm (ft/in)	2300 (7 ft 7 in)
Ground clearance, mm (inches)	295 (12)
Width Over tires - Std, mm (ft/in)	2090 (6 ft 10 in)
Height - Pivot Pin, mm (ft/in)	3350 (11 ft )
Reach - At 2130mm 45° Dump, mm (ft/in)	1660 (5 ft 5 in)
Fuel Tank, ltr (gallons (US))	90 (23.8)
Hydraulic Tank, ltr (gallons (US))	66 (17.4)
Heaped Capacity, m³ (yd³)	1.1 (1.4)
Breakout - Bucket, kgf (lbf)	5650 (12456)
Ride Control System	Optional
Pump Type	Gear
Pump Flow - 1, lt/min (gallons (US) / min)	93 (25)
System Pressure, bar (PSI)	189.6 (2750)
